St. Steel - Wing nuts

GN 432


d1 d2   d3 b h t
            min.

25 M 6 8 8 10 7
30 M 6 M 8 10 10 12 9
36 M 8 M 10 12 12 14,5 10
Specification Information How to order
Stainless Steel
Sintered
German Standard
No. 1.4404

matt shot-blasted

St. Steel-Hand knobsGN 5334

St. Steel-Hand knobsGN 5335

St. Steel-Wing nut
GN 432-25-M6

Code No. 432
d1 25
d2 M6
